Deep Groove Ball Bearing Manufacturer

TTBC and HMD brand deep groove ball bearings are a highly versatile, standardized, and serialized basic component. Rolling bearing is a precision mechanical component that changes the sliding friction between the running shaft and the shaft seat into rolling friction, thereby significantly reducing friction loss. Due to the different working conditions of various machinery, there are various requirements for the load capacity, structure, and performance of rolling bearings. Therefore, rolling bearings require various structures. The most widely used is deep groove ball bearings, which are composed of inner rings, outer rings, steel balls, cages, lubricating grease, and seals. TTBC and HMD brand bearings can be produced in various sealing forms: RZ, ZZ, RS, 2RS, UG, pure open.

The application performance of deep groove ball bearings is determined by some performance parameters and must be carefully selected to meet the usage requirements. Therefore, it is necessary to focus on the following elements:

Working load - Steel ball size, specification and quantity, inner and outer ring wall thickness

Working temperature - material, heat treatment, lubricating grease, sealing components

Working speed - parameter selection, lubricating grease, cage, sealing form

Working environment - materials, lubricants, sealing forms

Tolerance fit - radial clearance

Installation form - lubricating grease, sealing form (horizontal or vertical)

Complex loading form - pure radial or axial, both, unstable impact

Others - Inner circle rotation or outer circle rotation

TTBC and HMD brand bearings have a wide range of applications and are widely used in industries such as automobiles, motorcycles, motors, household appliances, sports equipment, office supplies, agricultural machinery products, etc. They are exported to Southeast Asia, Europe and America, the United States and Canada, the Middle East, and other regions, and have won unanimous praise from customers.

TTBC and HMD brand bearings have the following characteristics:

1. Super strong bearing capacity;

2. Quick rotation;

3. Durable and durable, with a long service life;

4. High quality and precision bearings;

5. High temperature resistant design bearings;

6. Ultra quiet design makes your device more comfortable;

7. A bearing brand with a long history and is trustworthy;

8. Bearings have a wide range of applications.

TTBC and HMD brand bearing rings and steel balls are made of GCr15, and different materials can also be used according to customer actual needs; The cage is usually made of 0.8F cold rolled steel plate, stamped, and there are also plastic and nylon cages.

The accuracy of TTBC and HMD brand bearings is divided into five levels: 0, 6, 5, 4, and 2, and the tolerance level follows the GB/T307.1-2005 standard. The radial clearance is divided into five groups according to the ISO5753 standard: C0, C2, C3, C4, and C5.
