Analysis of typical application scenarios of Flange Series Deep Groove Ball Bearing in automation equipment

In the field of industrial automation, efficient and reliable mechanical transmission components are the key to ensuring the stable operation of equipment. Flange Series Deep Groove Ball Bearing has become an important component in automation equipment due to its compact design, high load-bearing capacity and easy installation.
1. Industrial robot joints and transmission systems
Industrial robots have extremely high requirements for the accuracy, rigidity and durability of bearings. Flange series deep groove ball bearings can effectively withstand radial and axial composite loads due to their integrated flange design of inner and outer rings, and are often used in the rotating parts of robot joints. For example, the Z-axis lifting mechanism and joint wrist of SCARA robots rely on such bearings to achieve high-precision positioning and low-friction operation, ensuring repeated positioning accuracy within ±0.01mm.
2. Automated production line conveyor module
In scenarios such as assembly line conveyor belts and sorting robot arms, the sealing performance and anti-pollution ability of flange bearings are particularly important. Its flange structure can be directly fixed on the equipment bracket, eliminating the need for additional bearing seats and simplifying the installation process. For example, in food packaging production lines, stainless steel flange bearings can withstand frequent flushing and high-temperature steam sterilization to prevent grease leakage from contaminating products.
3. Servo motors and stepper motors
High-speed servo motors require bearings with low noise and low heat generation characteristics. Flange deep groove ball bearings significantly reduce vibration during high-speed operation by optimizing raceway design and cage materials (such as nylon or copper), and are suitable for precision motors in CNC machine tool spindles and semiconductor equipment. Test data of a certain brand of servo motors show that after using flange bearings, the temperature rise is reduced by 15% and the life is extended by 20%.
4. Medical equipment and laboratory instruments
Medical automation equipment (such as PCR instruments and infusion pumps) has strict requirements on the cleanliness and quietness of bearings. Flange bearings can be used with special lubricants (such as perfluoropolyether grease) or ceramic ball materials to meet the needs of dust-free environments. Its preloaded installation method can also eliminate axial clearance and avoid detection errors caused by slight vibrations of the instrument.
5. Logistics AGV trolley drive unit
The driving wheels of automated guided vehicles (AGVs) are often supported by flange bearings, whose high-rigidity structure can cope with frequent starts and stops and impact loads. A case of a logistics equipment manufacturer shows that after using flange bearings with sealing rings, the maintenance cycle of AGVs in storage environments has been extended from 3 months to 1 year, significantly reducing downtime costs.
Summary of technical advantages
Space saving: The flange design eliminates the bearing seat and is suitable for compact equipment.
High integration: supports direct installation on panels or housings, reducing assembly processes.
Multi-scenario adaptation: optional seals (ZZ/2RS) or open structures to adapt to different working conditions.
As automation develops towards intelligence, the innovative applications of Flange Series Deep Groove Ball Bearing will continue to expand. Engineers need to combine load, speed and environmental requirements when selecting to maximize their performance potential.
